Primary tracheal synovial sarcoma: a rare clinical entity with diagnostic challenges

Abstract

Background

The incidence of primary tracheal tumors is very low. Tracheal synovial sarcoma (SS) is even an extremely rare entity. Diagnosis of tracheal SS can be achieved with chromosomal translocation studies along with immunohistochemistry. Margin-free resection is the gold standard treatment.

Case presentation

We report a case of tracheal SS, which presented with stridor with a history of chronic cough and was diagnosed with a battery of clinical investigations and managed successfully with tracheal resection surgery. In histology, it may mimic Ewing’s sarcoma. Immunohistochemically, SS stains positive for cytokeratin, epithelial membrane antigen, vimentin, and S100. Chromosomal translocation t(X;18) (p11;q11) is found in almost all SS. This genetic signature is the gold standard diagnostic modality for these tumors.

Conclusion

Diagnosis of tracheal synovial sarcoma is challenging because of the rarity of the disease and common presenting symptoms to other tracheal pathology and is supplemented with chromosomal translocation study along with histopathology and immunohistochemistry. Tumor coring before definite surgical resection facilitates lung perfusion in obstructive tracheal pathology. A multidisciplinary team approach for diagnosis and management along with long-term follow-up are warranted.

Background

Soft tissue sarcoma of the head and neck region consists of less than 10% of all soft tissue sarcoma [1]. The heterogeneity of histology is responsible for a wide variety of clinical presentations. The management protocol includes surgery/radiotherapy/chemotherapy/combination therapy. Tracheal tumors are an uncommon group of tumors, accounting for less than 1 % of all malignant tumors [2], of which a small percentage are mesenchymal in origin. Less than 3% of synovial sarcoma (SS) arises in the head and neck region [3]. Tracheal SS is even rarer. There is a scarcity of data in the literature. Hence, the management of the tracheal soft tissue sarcoma and it’s outcome are not assessed accurately. Here, we report a case of primary tracheal monophasic SS and the diagnostic dilemma associated with it.

Case presentation

A 26-year-old non-smoker female with no medical comorbidities and no relevant family history, who was having a cough for 3 months, presented to the emergency room with progressively increasing stridor. The patient was acyanotic and was having tachypnea with labored breathing. Chest X-ray was suggestive of right lung collapse. The computed tomography (CT) scan of neck and chest (done outside before presentation to our institute) demonstrated a 20 × 17 mm tracheal mass just proximal to the carina, on the right posterolateral side, occluding the tracheal lumen with no extraluminal extension. There was no regional lymphadenopathy or distant metastasis (Fig. 1a–d).

Fig. 1
figure1

Sagittal (a), coronal (b), axial (c), and lung window (d) views of CT scans of thorax show a well-defined polypoidal soft tissue density lesion (solid yellow arrows) on the right posterolateral side of trachea at T4 vertebral level with gross luminal compromise, just proximal to carina with no extra luminal extension, laryngotracheal deviation, and lung collapse

Evaluation with fiber optic bronchoscopy (FOB) was done to assess the nature and extent of disease along with the feasibility of therapeutic debulking/coring. On bronchoscopy, there was an exophytic sessile obstructing ulcero-proliferative growth of size approximately 2 × 2 cm just proximal to the carina and extending for 2.5 cm above it. Tumor coring was facilitated with a rigid bronchoscope under sedation (Fig. 2a–d). Histopathology of the debulking specimen was suggestive of neuroendocrine carcinoma, being focally immunopositive for pancytokeratin and synaptophysin, while immune-negative for chromogranin and TTF-1. Ki-67 labeling index was 20–30% in the highest proliferation area.

Fig. 2
figure2

a Pre-debulking rigid bronchoscopy showing polypoidal obstructing growth, just proximal to the carina. bd Post-debulking bronchoscopy showing residual tracheal tumor with normal distal tracheobronchial airways

After symptomatic improvement with debulking, the patient was planned for definitive surgery two weeks later. Vitals parameters were in the normal range. Her general and systemic examination findings were essentially normal, except for respiratory system evaluation; there were decreased breath sounds on the right side with focal crepitations. Hematological work-up was normal. Post-tumor debulking/coring, Pulmonary function test (PFT) demonstrated forced expiratory volume in 1 s (FEV1) and forced vital capacity (FVC) 2.07 L (75% of predicted) and 3.28 L (94% of predicted) respectively.

The surgery was planned through the right postero-lateral muscle-sparing thoracotomy approach along the fourth intercostal space using isolated left lung ventilation on total intravenous anesthesia. Intraoperatively, there was an ulcerative tumor of size 1.5 × 1.0 × 1.0 cm in the right posterolateral wall of the trachea, starting just proximal to the carina and extending 2 cm above it. There was no paratracheal extension. The patient underwent tracheal resection with subcarinal and paratracheal lymphadenectomy with tracheoplasty after inferior pulmonary ligament release and hilar mobilization. The trachea was adequately mobilized on anterior and posterior aspects to facilitate tension-free tracheoplasty and the tracheal defect of ~ 3 × 2 cm was closed in transverse fashion using 4–0 interrupted absorbable monofilament sutures. Primary tracheoplasty was augmented with the pericardial fat pad. After the procedure, check FOB was done to ensure airtight closure. The patient was discharged on the fifth day of surgery after uneventful recovery. There were no early or late surgical morbidities.

Histopathological specimen comprised grossly of a fragment of the cartilage of size 1.5 × 1.0 cm with attached tumor tissue 1.5 × 1.0 cm (Fig. 3). The cut surface of the tumor was yellowish-white. Sections from the tumor revealed a small round cell tumor arranged in sheets. All resected margins (anterior, inferior, subcarinal, and right lower paratracheal) and dissected 3 lymph nodes adjacent to the main specimen were free of tumor. Immunohistochemically, tumor cells were immune-positive for EMA, BCL2, MIC-2, and TLE1, while immune-negative for TTF-1, chromogranin, desmin, and myogenin. MIB-1 index was around 50–60%. Overall morphological and immune-histochemical features were favoring synovial sarcoma with a differential diagnosis of Ewing’s sarcoma (ES). Fluorescence in situ hybridization (FISH) analysis for SS demonstrated dual-color break-apart rearrangement probe (Vysis) which indicates t(X;18)(p11.2;q11.2), reciprocal translocation between SS18 gene on chromosome 18 (18q11.2), and SSX gene on chromosome X (Xp11.2) causes the presence of SS18-SSX fusion gene (Fig. 4). FISH analysis for ES did not show dual-color break-apart rearrangement probe (Vysis) which indicates the absence of t(11;22)(q24;q12), translocation between EWSR1 gene on chromosome 22 (22q12), and FLI-1 gene on chromosome 11 (11q24) causes the EWSR1/FLI-1 fusion gene. Based on these histological, immunohistochemical, and molecular genetic analyses, a final diagnosis of synovial sarcoma of the trachea was considered.

Fig. 3
figure3

Gross specimen of tracheal tumor with tracheal cartilage

Fig. 4
figure4

Microscopic pictures from tracheal mass shows a tumor composed of monomorphic small round cells arranged in sheets (a; H&E, 100×), tumor shows immunopositivity for epithelial membrane antigen (EMA) (b; 100×), bcl2 (c; 200×), MIC2 (d; 200×), and TLE1 (e; 100×). Interphase fluorescent in-situ hybridization for translocation (X;18) (SYT Vysis break-apart probe) shows a separation of the 5′ and 3′ SYT signals in many of the tumor cell nuclei (arrows)

Because of small-sized primary tracheal synovial sarcoma with negative margins dissection, no adjuvant treatments were advised in a multidisciplinary tumor board meeting. The patient was kept on follow up with clinical examinations and serial chest X-ray and FOB. One year after surgery, there was locoregional control and had no distant metastases in chest X-ray imaging (Fig. 5).

Fig. 5
figure5

Chest X-ray showing normal post-operative change in trachea (black arrow) with no lung metastasis

Discussion

Primary tracheal SS is extremely rare. A couple of case reports of primary tracheal SS are reported in the English literature [4, 5]. Corrales et al. did a surgical resection of primary cervical synovial sarcoma and primary anastomosis assisted by laryngeal-releasing maneuvers, without any complication. The author confirmed the diagnosis by demonstrating the SYT-SSX gene rearrangement and ascertained that surgery was the first-line treatment for such malignancy. Sykes et al. did en bloc tumor excision with trachea through a low collar incision by the neck approach and primary end-to-end tracheal anastomosis was performed. The patient received a total dose of 62 Gy external beam irradiation in 22 fractions of 180 cGy and boost therapy in 12 fractions of 180 cGy. No adjuvant chemotherapy was administered to this patient. The author concluded that surgery was the optimal treatment modality. The treatment outcome was good in the above-mentioned literature with no evidence of locoregional disease recurrence or distant metastasis. Likewise, our patient is also disease-free until the last follow-up date. These tumors grow intraluminally and are diagnosed only after a significant portion of the lumen is compromised.

Synovial sarcoma should be excluded from Ewing’s sarcoma. SS is a clinically distinct entity. It is reclassified into three sub-types: monophasic, biphasic, and poorly differentiated variants [6]. Poorly differentiated sub-type has aggressive clinical behavior. MIC2 gene expression is usually found in ES [7]. Chromosomal translocations t(11;22) (q24;ql2) and t(21;22) (q22;ql2) are considered to be specific for PNET/ES, while t(X;18) (p11;q11) translocation is specific for SS [7]. Hence, immunohistochemical and genotypic analyses are considered to be effective diagnostic tools.

There is no specific staging system for tracheal sarcoma, because of a small number of cases with mixed histology and insufficient information about survival. So, there are no clear guidelines for diagnosis and management. Optimal treatment is en bloc surgical resection with negative margins. Debulking before the definite surgical resection is required to improve respiratory distress. It is an effective and safe procedure for airway obstruction due to tracheobronchial tumors [8]. The histology of debulking specimen in the present case renders the diagnosis of neuroendocrine carcinoma (NEC). The most common neuroendocrine carcinoma is carcinoid tumor and it has low malignant potential and has a comparatively good prognosis. Microscopically, these tumors have large polyhedral cells with hyperchromatic nuclei

Often anaplastic cells, areas of necrosis and high mitotic figures are also seen. Tumor cells are usually immunopositive for chromogranin, synaptophysin, pancytokeratin, CEA, calcitonin, and p53, while immunonegative for TTF-1 [9].

Nevertheless, the surgical management of lower tracheal tumor is always a challenge given difficult access, being surrounded by vital organs. In general, adjuvant chemoradiotherapy is advocated for high-grade sarcoma. The prognosis of head and neck SS depends on tumor grade, extent, and size. But because of the rarity of tumor, there are no definite protocols for adjuvant treatment and follow-up. Histopathological diagnosis is a challenge to differentiate between synovial sarcoma and Ewing’s sarcoma, which may mimic each other. The value of FISH translocation studies to make a specific diagnosis cannot be overemphasized. In literature, local recurrence and distant metastasis in head and neck sarcomas are reported as late as 62 months after surgery, so long-term follow-up with serial imaging and FOB is indicated in such rare aggressive tumor [10]. Six monthly follow-up was advised for the first five years after surgery and thereafter annually.

Conclusion

Tracheal SS needs stringent clinical diagnostic evaluation for attaining a definite diagnosis. The clinical symptoms may be misleading. Histology, immunohistochemistry, FISH analysis for chromosomal translocation studies are vital for accurate diagnosis of this rare clinical entity. A multidisciplinary approach for diagnosis and management along with long-term follow-up is always desirable. Targeting the characteristic chromosomal translocation t(X:18) helps in making a specific diagnosis and further management of this tumor.

Availability of data and materials

All data generated or analyzed during this study had already been included in this manuscript. Patient’s case file was retrieved from the medical record section of the institution. The clinical data had been collected from the prospectively maintained computerized database and the case file. The follow-up status was updated from the above-mentioned manner.

Abbreviations

CT:

Computed tomography

ES:

Ewing’s sarcoma

FEV1:

Forced expiratory volume in 1 s

FISH:

Fluorescence in situ hybridization

FOB:

Fiber optic bronchoscopy

FVC:

Forced vital capacity

PFT:

Pulmonary function test

SS:

Synovial sarcoma

References

  1. 1.

    Mendenhall WM, Mendenhall CM, Werning JW, Riggs CE, Mendenhall NP. Adult head and neck soft tissue sarcomas. Head Neck. 2005;27:916–22.

    Article  Google Scholar

  2. 2.

    Nouraei SM, Middleton SE, Nouraei SAR, Virk JS, George PJ, Hayward M, et al. Management and prognosis of primary tracheal cancer: a national analysis. Laryngoscope. 2014 Jan;124(1):145–50.

    Article  Google Scholar

  3. 3.

    Pai S, Chinoy RF, Pradhan SA, D’Cruz AK, Kane SV, Yadav JN. Head and neck synovial sarcomas. J Surg Oncol. 1993;54:82–6.

    CAS  Article  Google Scholar

  4. 4.

    Corrales CE, Berry G, Damrose EJ. Primary cervical tracheal monophasic synovial sarcoma confirmed by SYT-SSX gene rearrangement. J Laryngol Otol. 2011;125:651–4.

    CAS  Article  Google Scholar

  5. 5.

    Sykes AT, Rokkas CK, Kajdaesy-Balla A, et al. Primary tracheal synovial cell sarcoma: A first case report. J Thoracic Cardiovasc Surg. 1997;114:678–80.

    CAS  Article  Google Scholar

  6. 6.

    Cadman NL, Soule EH, Kelly PJ. Synovial sarcoma. An analysis of 134 tumors. Cancer. 1965 May;18(5):613–27.

    CAS  Article  Google Scholar

  7. 7.

    Ladanyi M. The emerging molecular genetics of sarcoma translocations. Diagn Mol Pathol. 1995 Sep;4(3):162–73.

    CAS  Article  Google Scholar

  8. 8.

    Vishwanath G, Madan K, Bal A, Aggarwal A, Gupta D, Agarwal R. Rigid Bronchoscopy and Mechanical Debulking in the Management of Central Airway Tumors: An Indian Experience. J Bronchology Interv Pulmonol. 2013 Apr;20(2):127–33.

    Article  Google Scholar

  9. 9.

    Tartour E, Caillou B, Tenenbaum F, Francese C, Ruffie P, Schlumberger M. Neuroendocrine tumor of the trachea of the intermediate type. Value of its individualization. Presse Med. 1992 Nov 28;21(40):1905–8.

    CAS  PubMed  Google Scholar

  10. 10.

    Roth JA, Enzinger FM, Tannenbaum M. Synovial sarcoma of the neck: a followup study of 24 cases. Cancer. 1975;35:1243–53.

    CAS  Article  Google Scholar

Download references

Acknowledgments

We thank Dr. Karan Madan, Assistant Professor, Pulmonary Medicine and Sleep Disorders, AIIMS, New Delhi, for pre-operative coring of the tracheal tumor and referring the patient for further surgical management.

Funding

This research did not receive any special grant from funding agencies in the public, commercial, or not-for-profit sectors.

Author information

Affiliations

Authors

Contributions

NK made substantial contributions to the conception or design of the manuscript, data collection, and manuscript writing. SK gave final approval of the manuscript version to be published. KK helped in data collection. MG helped in manuscript editing and proofreading. SKR drafted the work or revised it critically for important intellectual content and to be accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of the manuscript. All authors have read and approved the manuscript.

Corresponding author

Correspondence to Sunil Kumar.

Ethics declarations

Ethics approval and consent to participate

Ethics approval is not applicable to retrospective treated individual case reports. The patient’s informed written consent had been taken concerning participation for this particular case report.

Consent for publication

Written informed consent to publish the patient’s clinical details information was obtained from the study participant. Authors also give full consent to the publisher, including reading and editing for the publication of this study.

Competing interests

The authors reveal no competing interests in the research.

Additional information

Publisher’s Note

Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Rights and permissions

Open Access This article is distributed under the terms of the Creative Commons Attribution 4.0 International License (http://creativecommons.org/licenses/by/4.0/), which permits unrestricted use, distribution, and reproduction in any medium, provided you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made.

Reprints and Permissions

About this article

Verify currency and authenticity via CrossMark

Cite this article

Kumar, N., Kaushal, S., Kanaklata, K. et al. Primary tracheal synovial sarcoma: a rare clinical entity with diagnostic challenges. J Egypt Natl Canc Inst 32, 3 (2020). https://doi.org/10.1186/s43046-019-0014-z

Download citation

Keywords

  • Tracheal tumors
  • Synovial sarcoma
  • Tracheal resection
  • Tracheoplasty
